| Screen Model |
LTA150XH-L06 |
Screen Size |
15.0″ |
| Resolution |
1024(RGB)×768, XGA 85PPI |
Brightness |
400cd/m² (Typ.) |
| Active Area |
304.128(W)×228.096(H) mm |
Outline Dim |
331.6(W)×254.8(H) ×13(D) mm |
| Treatment |
Antiglare (Haze 25%), Hard coating (3H) |
Contrast Ratio |
400:1 (Typ.) (TM) |
| Viewing Angle |
70/70/60/65 (Typ.)(CR≥10) |
Operating Mode |
TN, Normally White, Transmissive |
| Frame Rate |
60Hz |
Light Source |
4 pcs CCFL , 35K hours , Without Driver |
| Interface Type |
LVDS (1 ch, 8-bit) , 20 pins Connector |
Power Supply |
3.3V (Typ.) |
| Operating Temperature |
0 ~ 50 °C |
Storage Temperature |
-25 ~ 60 °C |
